In the main view, the zoom wheel works as expected, allowing zoom out and in.
In the face designer it always zooms in whether turning the wheel forward or back.

Is this still strue with the extruded sides? It looks like there is an offset in both Z and Y of say the bottom origin compared to the front origin.

@Colin how do I:
[quote="Colin"edit the front panel so it extended past the sides of the extrusion and add the rack mounting slots into over hanging material.[/quote]

Thanks, that should save some time from having to run lots of instant pricing. It might help if these pricing formulas were published rather than having to use the software to reverse engineer them.

Extending the front panel is a great idea, but I can't figure out how to do it in the software. If I widen the housing properties, the top and bottom also expand. And I can't seem to edit the outline of the face. I'd like the use the Extruded D type, so the front panel needs a recess on top and bott...

All the extruded 1U housing types seem to lack 19" rackmount brackets. What is the easiest way, can off the shelf brackets be used ?

I am designing a 1U rackmount case, where cost is very important. There are so many choices and I cannot easily see how the price is effected. Which are the most economical 1U 16.125x8" : Type: Extruded (A,B,C,D,E,F) , Rackmount or rear bend rackmount? Finish (Black): Sandtex, Full Gloss or Flat? Si...
